整机性能Specifications

额定载荷Rated operating capacity(kg)

500

倾翻载荷Tipping load(kg)

1000

铲斗容量Bucket capacity(m3)

0.25-0.4

机器操纵质量Operationg weight(kg)

2200

行驶速度Max. travel speed(km/h)

12

工作流量Hydraulic pump flow(L/min)

75

油箱容量Fuel tank capacity(L)

50

轮胎型号Tires

27*8.5-15-8NHS

整车尺寸Overall dimensions(mm)

2900×2000×1300

整机参数Dimensions

最大操作高度Height at maximum extension(mm)

3300

铰接销高度Height to bucket hinge pin(mm)

2725

带斗宽度Width with bucket(mm)

1300

轮距Track width(mm)

1080

轴距Wheelbase(mm)

891

离地高度Ground clearance(mm)

150

倾倒角Dump angle

40°

倾倒高度Dumping height(mm)

2050

倾倒前伸Maximum reach(mm)

790

接近角Rollback at ground

26°

离去角Angle of departure

20°

发动机Engine

型号Maker/Model

YND485G

功率转速Net power

40hp/2600rpm

类型Type

直喷直列水冷四冲程柴油机
4Cylinder in-line, Water cooled, 4 stroke, Diesel engine

排量Displacement(L)

2.156

标准配置Standard

标准铲斗Standard bucket

开式驾驶室Open-type operator cab

液压伺服手动控制Hydraulic joystick controls

辅具输出装置Auxiliary hydraulic couplers

可选配置Optional

    封闭驾驶室

Enclosed operator cab

    低温起动装置

Prehest starting assist system for extreme cold weather

内置暖风

Cab fitted with a heater as standard

冷暖空调

Air conditioner
