整机性能Specifications

额定载荷Rated operating capacity(kg)

600

铲斗容量Bucket capacity(m3)

0.3

机器操纵质量Operationg weight(kg)

2800

行驶速度Max. travel speed(km/h)

8

工作流量Hydraulic pump flow(L/min)

40

油箱容量Fuel tank capacity(L)

50

整车尺寸Overall dimensions(mm)

2050×2950×1500

整机参数Dimensions

铰接销高度Height to bucket hinge pin(mm)

2770

带斗宽度Width with bucket(mm)

1500

履带宽度(mm)

320

履带地面长度(mm)

1240

离地高度Ground clearance(mm)

180

发动机Engine

型号Maker/Model

扬动YND485G /进口英国帕金斯Perkins 404D

功率转速Net power

48hp/2500rpm

类型Type

直喷直列水冷四冲程柴油机
4 Cylinder in-line, Water cooled, 4 stroke, Diesel engine

排量Displacement(L)

2.2

标准配置Standard

标准铲斗Standard bucket

封闭驾驶室Open-type operator cab

液压伺服控制(单手行驶)Hydraulic joystick controls

辅具输出装置Auxiliary hydraulic couplers

可选配置Optional

内置暖风Cab fitted with a heater as standard

冷暖空调Air conditioner

辅具Attachments：

挖掘机、破碎锤、推土板、钻孔机、清扫机、叉铲、开沟机、抓木叉、组合铲等
Backhoe,Breaker,Angle blade,Auger,Sweeper,Pallet fork,Combinition bucket,Mower,Asphalt cutter,and More
